Product Details
＋
| Product Attribute | Attribute Value |
|---|---|
| Agency Approvals | UL, cULus, CSA, VDE |
| Alternate Mfr Part Number | IC 2 5/ 4-ST-5 08 |
| Approvals | CSA, UL Recognized, VDE Gutachten mit Fertigungsüberwachung, cUL Recognized, IECEE CB Scheme, EAC, cULus Recognized |
| Body Color | Green |
| Color | Green |
| Current Rating | 12 A |
| Current, Nominal | 12 A |
| Family Name | COMBI Plug Family |
| Level | Single Level |
| Mounting Type | PCB Mount |
| Number of Levels | 1 Level |
| Number of Positions | 4 Position |
| Pin Spacing | 5.08 mm(0.2 in) |
| Pitch | 5.08 mm |
| Primary Type | Wire to Board |
| Series | |
| Termination | Socket |
| Type | Plug |
| UPC Code | 4017918042349 |
| Voltage Rating | 250 V |
| Weight | 0.0071 KG |
| Wire Entry | Front |
| Wire Size | 12-24 AWG |
| Wire Termination Type | Screw |
Overview
Phoenix Contact COMBICON Power Connection Family | COMBICON ICC Series — Plugs with Inverted Contact System:
Free hanging inline connectors with a crimp connection.
Features:
ICC Series Accessories Features:
